HPE ProLiant MicroServer Gen10 Plus Xeon E-2224 16GB S100i Server

(5957448)

Categories: , , ,

Are you a small office, home office or small business with branch offices looking to build a customized solution for your office?
The HPE ProLiant MicroServer Gen10 Plus delivers an affordable compact yet powerful entry level server that you can customize for on-premises or for hybrid cloud possibilities. It is the most compact MicroServer that we have launched so far, which can be placed flat or vertically depending on your space. The latest Intel® Xeon® E and Pentium® processors deliver compute performance as well as security and remote management into the server with HPE iLO Silicon Root of Trust. Along with other enhancements such as 4X 1GbE onboard NICs and USB 3.2 Type A Gen2, you will be surprised that there is nothing Micro about the HPE ProLiant MicroServer Gen10 Plus.

Product Specifications

Chassis
Form Factor :Tower
Manufacturer Form Factor :Ultra micro tower
Server Storage Bays :Non-hot-swap
Server Swappable Drive Form Factor :3.5″
Server Swappable Drive Form Factor (metric) :8.9 cm
Server Swappable Drive Interface :SATA
Internal Bays Qty :4

Processor
Type :Xeon
Number of Cores :Quad-Core
Processor Number :E-2224
Installed Qty :1
Max Supported Qty :1
Server Scalability :1-way
Upgradability :Upgradable
Manufacturer :Intel
Clock Speed :3.4 GHZ
Max Turbo Speed :4.6 GHZ
Processor Main Features :Intel Smart Cache, Intel Turbo Boost Technology 2

Cache Memory
Per Processor Size :8 megabyte, 8 megabyte
Installed Size :8 megabyte

RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :16 GB
Max Supported Size :32 GB
Configuration Features :1 x 16 GB
Data Integrity Check :ECC
Slots Qty :2
Empty Slots :1
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Memory Specification Compliance :PC4-21333
Features :Unbuffered

Type :RAID
Bus Type :PCI Express 3.0 x4
Interface Type :Serial ATA-600
Storage Controller Name :HPE Smart Array S100i SR Software RAID
Channel Qty :14
Installed Qty :1
RAID Level :RAID 0, RAID 1, RAID 10, RAID 5

Networking
Ethernet Controller(s) :Intel I350-AM4
Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :4 x Gigabit Ethernet
Remote Management Protocol :IPMI 2.0, SMASH CLP, SNMP 3
Features :ACPI support, PXE support, Wake on LAN (WoL)

Expansion Bays
Bays :4 (total) / 4 (free) x internal 3.5″ LFF

Expansion Slots
Slots :1 (total) / 1 (free) x expansion slot (iLO Enablement Kit slot), 1 (total) / 1 (free) x PCIe 3.0 x16 – low-profile

Interface Provided
Interfaces :1 x DisplayPort, 1 x VGA, 2 x USB 3.2 Gen 2 (2 in front), 4 x LAN (Gigabit Ethernet), 4 x USB 3.2 Gen 1

Power Device
Type :Power adapter
Power Provided :180 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz

Service & Support Details
Service & Support :Limited warranty – parts and labor – 1 year – on-site – response time: next business day
